August 8, 2017

The Ship is a Microgrid Part I: Why is This so Hard to Design and Build?

Written by | Matt Baker

Reading time | 3 minutes

In the realm of naval and merchant marine ships, the concept of a ship as a microgrid—comprising interconnected loads and distributed energy resources—has gained significant importance due to increasing electrification and computerized control. The complexity of power electronic design at both the component and system levels is magnified by multi-physics interactions and the long service life of these vessels. To address these challenges, the integration of Digital Twin and Hardware in the Loop (HIL) technology, such as the Typhoon HIL Marine Microgrid Testbed, offers a groundbreaking approach. This technology enables real-time simulation and detailed modeling of microgrid interactions, ensuring stability and readiness over decades of service while handling the intricate dynamics of shipboard power systems.

Introduction

The ship is a microgrid with interconnected loads (propulsion, C4ISR, propulsion, and auxiliary) and distributed energy resources (power generation, distribution, and energy storage) acting as a controllable entity. This is not a new concept. However, it is one that is taking on far greater significance with the increasing electrification and computerized control of naval and merchant marine ships.

Power electronic design is complicated at the load and distributed energy resource component level. Interconnecting and controlling multiple components to make a microgrid is orders of magnitude more complex due to multi-physics interactions (electrical, thermodynamic, mechanical, and control) occurring at sub-microsecond frequencies. Add life-cycle requirements over 25-50 years of service, and system engineering shipboard microgrids become a staggering problem set.

Put another way for the Navy: If firing a laser aboard a ship is complicated, then fighting the interconnected and computer-controlled electric ship is orders of magnitude more complex. The effect of firing a laser is analogous to light dimming and problems maintaining the Internet when lightning strikes. Fighting a future ship will involve firing multiple directed energy and electromagnetic weapons repeatedly; high power sensors “painting” the sky; electric drive motors executing evasive maneuvers; and all while maintaining the ability to fight fires, isolate damage, and keep the computer network from dropping. The shipboard microgrid must remain stable while handling hundreds of lightning-strike-like events in a short amount of time.

Digital Twin and Hardware In the Loop for shipboard power system engineering

Building a microgrid platform like the one described and maintaining its readiness and capability over a 25-50 year lifespan, with constant repairs, replacements, and upgrades of power electronic components, requires a new approach and game-changing tools. The Digital Twin is the new approach and Typhoon HIL Hardware In the Loop technology is the game changer.

Typhoon HIL equipment, configured as a Marine Microgrid Testbed, provides the only testing and modeling solution that enables true real-time simulation of microgrid component interactions at system and sub-system levels required. In practical terms, our platform is capable of 500 ns simulation time steps with 20 ns data sampling rates. This best-in-class performance is achieved using purpose-built hardware with up to 128 cores of processing power programmed with a vertically integrated, easy-to-use, and fully supported software toolchain designed specifically to fully utilize this massive processing power. Moreover, designers can draw upon our growing digital library of generic and COTS components to speed up their efforts while maintaining peerless analytical quality.
