Introduction
Hardware-in-the-loop (HIL) is not a new technology. It has been around for twenty-five-plus years, and it has been almost exclusively used in the automotive and aerospace industries for test and validation of controller performance and system integration. Although HIL has been synonymous with automotive testing; this is changing.
In 2015, three independent market research companies published three “State of the HIL” reports. All three reports state that after decades of evolutionary HIL developments, there is a new application – HIL for power electronics and power systems.
Although the HIL market for power electronics, microgrids, and power systems is still smaller than either automotive or aerospace, it is the fastest-growing segment. The power electronics and microgrid pull is tremendous. Here are a few excerpts from VDC, Markets and Markets, and Frost and Sullivan reports.
“HIL tool spending will grow most rapidly in the energy/power industry…”
“…HIL adoption is accelerating outside of the legacy user base (automotive and aerospace/defense). The rapid expansion of HIL use in several industries including energy/power is helping drive revenue growth.”
“The market for the power electronics sector is expected to witness the highest growth rate of 14.36% from 2015 to 2020 as a result of the increasing use of hardware in the loop hardware and software.”
“The overall hardware in the loop market is expected to grow at a rate of 9.37% between 2015 and 2020. The market for the power electronics sector is expected to grow at a high CAGR of 14.36% between 2015 and 2020.”
“Frost & Sullivan expects the power electronics HIL segment to witness huge growth and reach $100 million in the next 10 years.”
The four key drivers that are fueling the rapid ascent of HIL for power electronics and microgrids are:
1. Power electronics are becoming ubiquitous.
Power electronics converters are everywhere. From low-power laptops and phone chargers to hybrid and electric cars, PV inverters, and wind turbines, all the way to HVDC converters.
Today, 40% of all energy consumption is in electrical energy, but this will grow to 60% by 2040. Yet the share of electrical energy that is controlled by power electronics converters will increase from 40% to 80% by 2030.
When fully deployed, power electronics hold a promise to bring more than 30% electrical energy efficiency gain.
The goal of efficiently processing more than 50% (80% of 60%) of our civilization’s energy by smart power electronics converters, networked power electronics converters, adaptable power electronics converters, etc. will require new ways and processes for power electronics control design, testing, and deployment.
2. The grid is changing. Power electronics are driving the change.
As the grid penetration of renewables and distributed energy resources (DERs) is continuously increasing, the highly centralized grid as we know it today is getting transformed into a smart grid of tomorrow.
In 2015 alone 7GW of solar and 5 GW of wind was installed and the pace is only increasing. All of these DERs are interfaced to the grid with power electronics inverters that will soon become smart inverters. Testing against emerging smart inverter grid standards is becoming critical (i.e. BDEW, CEI 0-21, Rule 21, UL 1741 SA).
All the smart inverters on the grid, whether they control renewables or loads (e.g. variable speed drives) will be able to participate in grid control.
Inverters are getting smarter, and inverter controllers are becoming sophisticated. Increasingly sophisticated controllers require more extensive testing in an automated, safe, and repeatable process which can be achieved using proper hardware-in-the-loop testing practices and tools.
3. Microgrids are transforming distribution systems.
Microgrids, defined as power subsystems comprising loads and sources that can operate in both grid-tied and islanded modes, are gaining traction as a solution for better reliability, larger renewable penetration, and a more flexible grid.
Since microgrids are complex systems, the control and coordination of microgrids are becoming increasingly complex as well.
Hardware-in-the-loop testing is becoming the ubiquitous tool when it comes to microgrid controller development, testing, and commissioning.
4. Transportation is becoming more electric.
From hybrid and electric vehicles to hybrid off-road trucks and agricultural machinery, all the way to more electric and hybrid airplanes, and hybrid/electric ships we are witnessing a very robust trend in the electrification of transportation.
Electrical systems and hybridized systems are more flexible and more efficient. And power electronics is making it all possible, yet again.
As the electrification continues, system complexity is increasing, hence the need for more advanced design and testing methods. Indeed, Hardware in the Loop testing is starting to play a critical role in testing and test automation of these systems that are being controlled with tens of controllers running complex software/firmware and communicating over different communication networks.
